Artwork Print and Cut for Hori 2017 Fighting Edge (PS4 Model)

×
Rating
(5)
Price:
$15.95 (USD)
SKU
CUSTOM-EDGE-PS4-ART-TOP
Weight
3.00 Ounces
Availability
Please allow up to 7-10 business days to process custom orders. Order will appear in Custom Job Tracker.
Shipping
Calculated at checkout
Only supports a few types. Maximum file size: 244 MB
Quantity:
Description
Reviews
Videos
Warranty
Other Details

  • Product Description

    Please Read Before You Order

    Below is important information to know before placing a custom order with us:

    • Project L Official Artwork: Do not submit the PNG samples. Instead, please download the zipped Photoshop PSD version, unzip the file and integrate them into our artwork templates new-window-icon.png for your desired fightstick model
    • Hori Official Street Fighter 6 Artwork:  Please do not submit this artwork for the Fightstick Alpha. It is not compatible with our print and cut, as it contains registration marks that cannot be removed. If you wish to have the artwork printed only, you can use our Non-Commercial Fightstick Panel Artwork Print service.
    • Hori Official Tekken 8 Artwork. We can print and cut most of Hori's official Tekken 8 artwork, as they revised the artwork files to allow removing the registration marks. Exception is artwork for Jun Kazama which has registration marks that cannot be removed.
    • Custom Orders do Not Ship Separately: If you place an order for a personalized product along with non-custom products, such as arcade part or merchandise, please note that all items will ship together.

    Plexi Requirements
    Artwork for this Fightstick requires a plexiglass replacement. The original Fightstick panel contains artwork that is permanently attached to it, the panel was not originally designed to accomodate custom artwork, or did not come with a plexi panel. After adding custom artwork to your cart, look for the Fightstick Plexi that matches your Fighstick model.

    Control panel artwork represents one of the most convenient means to personalize your fightstick, giving it a new look almost immediately.

    High Resolution, Color Fidelity

    Artwork prints are developed using a top-of-the-line commercial printer, offering vivid, professional-quality artwork replication. The printer is capable of resolution of 1200dpi (dots per inch), and 8 color ink system (Cyan, Magenta, Yellow, K(Black) + Light Cyan, Light Magenta and White) reproduces artwork over a wide color range.

    Artwork is printed on 10 mil cardstock sheet. It carries 95% brightness and tensile strength of 100 pounds per inch.

    Each print is laser cut to your specifications, as presented by available options. You will receive the print with perforated button inserts designed to fit your chosen button brand. In some cases, such as the Mayflash series, the control panel elements may also have perforated cuts. Gently press downward to remove the cutouts.

    Important Notes about Color Fidelity, Brightness

    • Please do not change the RGB color space of our templates to CYMK when submitting your artwork. Our templates are intentionally designed in the RGB color space to best match most customer's screen expectations, and will typically convert CYMK to RGB when printing. We will not honor demands to reprint artwork whose template is changed to CYMK color space.
    • Unless properly calibrated to your printer and viewing environment, your monitor does not accurately represent the brightness of paper. Artwork submissions may need adjustment to ensure prints are not too dark. Please read this helpful support article for more information

    New: Holographic Paper

    Animated holograph paper example

    Example animated photo displayed for illustrative purposes only. Pattern "Space Dots" shown.

    In addition to white cardstock sheets, we now offer holographic paper sheets in several captivating patterns. Holographic sheets are created from paper that is imprinted or embossed with a design or image and then covered in a thin, transparent film of metal. The finished sheet has a characteristic luster — a kind of rainbow iridescence — when the imprinted pattern is viewed from particular perspectives.

    Holographic cardstock has a similar tensile strength to our existing cardstock, about 110-115 pounds per inch

    Differences between White Cardstock and Holographic Print

    Both materials have their strengths. White cardstock is our tried and true paper material, producing vibrant colors with a textured semigloss.  It's 95% brightness brings out the best color fidelity because it has a white backing.

    Holographic paper has a striking metallic finish. By itself, its color changing properties are quite eye-catching. This is even more evident when a pattern is used. However, because the material does not have a white backing, the illustration's areas of white will instead show the metallic sheen. This can lead to a slightly duller appearance compared to cardstock. These comparison photos may help to illustrate. Please note that while the colors can appear more muted on holograph paper, the reflective nature of the material as well as its color properties will vary depending on the angle the illustration is seen and the material's pattern. Not every print will exactly resemble the below example.

    White cardstock example
    Holographic paper example
    White cardstock
    Holographic paper

    Holographic Patterns

    To review the list of current patterns we offer, please click the "Option Guide" Tab, then click "Holographic Patterns" link. On a mobile device? Scroll down to "Options Guide", then click "Holographic Patterns" link.

    Sized for Hori Fighting Edge (PS4 Only). Install Notes

    Hori Fighting Edge (2017 PS4 Model)
    Fighting Edge Panel Template (2017 PS4 Model, 1.7Mb zip)

    The Hori Fighting Edge is one of the company's largest Fightsticks save for the enormous arcade authentic Hori VLX series. The control panel itself is quite large - over 17 inches wide. Please note this this service is NOT compatible with the older PS3 or Xbox 360 model.  Some important notes while installing and replacing your pushbuttons:



    Hori Edge PS4 Artwork/Plexi Install - Step 1 Hori Edge PS4 Artwork/Plexi Install - Step 2
    First, flip the Hori Edge Fightstick on its back to expose 8 screws you will remove to get inside the control panel.  The leftmost two screws will allow you to access the start button, which you must remove to free the metal panel With the bottom panel removed, inspect button wiring and joystick.  You will detach the wiring from each button in order to dislodge it from the panel.  The joystick shaft's balltop is also detached prior to removing the metal panel.
    Hori Edge PS4 Artwork/Plexi Install - Step 3 Hori Edge PS4 Artwork/Plexi Install - Step 4
    Please take note of the wiring color when reattaching the buttons:Make note of the original order of wiring and colors, including one ground for each command button:
    • Square = Blue
    • Triangle = Yellow
    • R1 = Red
    • L1 = Orange
    • X = Grey
    • O = Green
    • R2 = Black
    • L2 = Green
    		 With the smaller screws removed from the leftmost bottom panel, you will expose the Fightstick's start/option button.  Note that this button does not rest on an underlying metal panel.  This is because the Edge's original metal panel would serve this purpose. The replacement acrylic panel should manage the pressure without cracking, but take care not to jam the button in too hard when replacing it.  Detach the white wiring in order to remove the start button from the panel.
    Hori Edge PS4 Artwork/Plexi Install - Step 5 Hori Edge PS4 Artwork/Plexi Install - Step 6
    Remove the balltop connected to the joystick shaft by inserting a flathead screwdriver to the bottom of the shaft and turning the balltop counter-clockwise. Now, flip the Fightstick on its top, exposing the original metal panel.  Use a 4mm hex key (or 5/32") to unscrew each of the 6 screws at top.
    Hori Edge PS4 Artwork/Plexi Install - Step 7 Hori Edge PS4 Artwork/Plexi Install - Step 8
    An important note: under each top panel screw you will find a nut in the Fightstick housing.  Please keep these nuts, as you will need them to reattach the plexi panel.  They may fall out when the screws are removed. One way to address this for future installs is to apply some superglue to the area where the nut rests, then place the nut back and allow to dry/cure.  As you can see, the underlying panel does not extend the full length of the Fightstick. The acrylic should bear some of the pressure from the PS4 Start/Option button, located at the right. It is here that you will install your artwork and replacement plexi, then reverse the steps to reinstall buttons joystick balltop, wiring and bottom panel.
